12. Drain Filter


>> Download 12. Drain Filter documenatation <<

Text preview - extract from the document
                                           DRAIN FILTER
EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)

12.Drain Filter                                         6) Remove the bolt which installs the drain filter
                                                        and drain valve brackets on body, and remove
A: REMOVAL                                              them as a unit.
1) Disconnect the ground terminal from battery.




                                                                                             EC-00175
                                      FU-00009
                                                        7) Disconnect the evaporation hoses, and remove
2) Lift-up the vehicle.                                 the drain filter from the bracket.
3) Remove the canister.
4) Disconnect the connector from drain valve.

                                                                                      (A)
                                                                (B)




                                                                                              EC-00061


                                                              (A) Drain filter
                                      EC-00174
                                                              (B) Drain valve
5) Disconnector the evaporation hoses (A) from
joint pipes.




                                      EC-00053




                                                 EC(STi)-14
                                                DRAIN FILTER
                                                       EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)

B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  23 N
