15. Drain Valve


>> Download 15. Drain Valve documenatation <<

Text preview - extract from the document
                                           DRAIN VALVE
EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)

15.Drain Valve                                          6) Remove the bolt which installs the drain filter
                                                        and drain valve brackets on body, and remove
A: REMOVAL                                              them as a unit.
1) Disconnect the ground terminal from battery.




                                                                                             EC-00175
                                      FU-00009
                                                        7) Remove the drain valve from bracket.
2) Lift-up the vehicle.
3) Remove the canister.
4) Disconnect the connector from drain valve.
                                                                                      (A)
                                                                (B)




                                                                                              EC-00061


                                                              (A) Drain filter
                                                              (B) Drain valve
                                      EC-00174

5) Disconnect the evaporation hoses from drain
valve.




                                      EC-00208




                                                 EC(STi)-18
                                                DRAIN VALVE
                                                       EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)

B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  23 N
