>> Download 16. PCV Hose Assembly documenatation <<

Text preview - extract from the document

                                      PCV HOSE ASSEMBLY
EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)

16.PCV Hose Assembly
A: REMOVAL
CAUTION:
Removal is not allowed except for the damage
of PCV hose, diagnosis connector and PCV
valve.
1) Remove the intake manifold.

2) Remove the clamp using pliers, etc. and then re-
move the PCV hose assembly.




                                       EC-00215

B: INSTALLATION
NOTE:
Replace the clamp with a new one.
1) Install the PCV hose assembly and lock it with a
clamp clipped by pliers.




                                       EC-00216

2) Install the intake manifold.





                                                  EC(STi)-20
