Image preview - the first page of the document
04. Intake Duct


>> Download 04. Intake Duct documenatation <<

Text preview - extract from the document
                                                INTAKE DUCT
INTAKE (INDUCTION)

4. Intake Duct
A: REMOVAL
1) Disconnect the ground cable from battery.




                                           FU-00009

2) Remove the intake manifold.
3) Remove the sensor, engine harness and fuel
pipe attached to intake manifold.
4) Remove the intake duct from intake manifold.




                                           FU-01076

B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  19 N
