Image preview - the first page of the document
05. Intercooler


>> Download 05. Intercooler documenatation <<

Text preview - extract from the document
                                            INTERCOOLER
                                                                                         INTAKE (INDUCTION)

5. Intercooler                                            5) Separate the intercooler from throttle body.

A: REMOVAL
1) Disconnect the air by-pass hoses from intercool-
er.




                                                                                                     IN-00192

                                                          B: INSTALLATION
                                                          Install in the reverse order of removal.
                                        IN-00166
                                                          Tightening torque:
2) Separate the air by-pass valve from intercooler.         16 N
