Image preview - the first page of the document
>> Download 06. Turbocharger documenatation <<
Text preview - extract from the document
TURBOCHARGER
INTAKE (INDUCTION)
6. Turbocharger 7) Loosen the clamp which secures the turbocharg-
er to intake duct.
A: REMOVAL
1) Set the vehicle on a lift.
2) Disconnect the ground cable from battery.
IN-00074
8) Remove the bolt which secures the bracket of oil
pipe to turbocharger.
FU-00009
9) Remove the oil pipe from turbocharger.
3) Remove the center exhaust pipe.
4) Lower the vehicle.
5) Separate the turbocharger joint pipe from turbo-
charger.
IN-00022
10) Disconnect the engine coolant hose.
11) Remove the turbocharger bracket.
IN-00019
6) Disconnect the engine coolant hose which is
connected to coolant filler tank.
IN-00172
12) Disconnect the oil outlet hose from pipe.
IN-00020
IN-00024
13) Take out the turbocharger from engine com-
partment.
IN(STi)-13
TURBOCHARGER
INTAKE (INDUCTION)
B: INSTALLATION 4) Install the joint pipe to turbocharger.
1) Connect the oil outlet hose to outlet pipe. NOTE:
Replace the gasket with a new one.
Tightening torque:
