Image preview - the first page of the document



>> Download 07. Air By-pass Valve documenatation <<

Text preview - extract from the document

                                           AIR BY-PASS VALVE
                                                                   INTAKE (INDUCTION)

7. Air By-pass Valve
A: REMOVAL
1) Remove the air by-pass valve from intercooler.




                                           IN-00167

2) Disconnect the air by-pass hoses from air by-
pass valve.
B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  16 N
