Image preview - the first page of the document



>> Download 09. Intercooler Water Spray Tank documenatation <<

Text preview - extract from the document

                             INTERCOOLER WATER SPRAY TANK
                                                                    INTAKE (INDUCTION)

9. Intercooler Water Spray Tank
A: REMOVAL
1) Disconnect the ground cable from battery.




                                           FU-00009
                                            G6M0095

2) Remove the trunk trim.
3) Disconnect the water tank connector.




                                            IN-00194

4) Remove the two water tank installation bolts.




                                            IN-00195

5) Remove the hose between body and water tank,
then remove the water tank.
B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  6.0 N
