14. Compulsory Valve Operation Check Mode


>> Download 14. Compulsory Valve Operation Check Mode documenatation <<

Text preview - extract from the document
                    COMPULSORY VALVE OPERATION CHECK MODE
                                                                                      ENGINE (DIAGNOSTICS)

14.Compulsory Valve Operation                              5) Connect the Subaru Select Monitor to data link
                                                           connector located in the lower portion of instrument
   Check Mode                                              panel (on the driver's side).
A: OPERATION
1) Prepare the Subaru Select Monitor kit.




                                                                                                    EN-01163

                                                           CAUTION:
                                                           Do not connect scan tools except for the Suba-
                                                           ru Select Monitor and OBD-II general scan tool.
                                         EN-00038
                                                           6) Turn the ignition switch to ON (engine OFF) and
2) Connect the diagnosis cable to Subaru Select            Subaru Select Monitor switch to ON.
Monitor.
3) Insert the cartridge into Subaru Select Monitor.                                           (A)





                                                                                                    EN-00040


                                                                  (A) Power switch

                                         EN-00039
                                                           7) On the
