Image preview - the first page of the document
>> Download 04. Select Cable documenatation <<
Text preview - extract from the document
SELECT CABLE
CONTROL SYSTEMS
4. Select Cable 9) Remove the plate assembly from transmission
case.
A: REMOVAL
1) Set the vehicle on a lift.
2) Set the select lever to "N" range. (A)
3) Disconnect negative cable from battery. (C)
4) Lift-up the vehicle.
5) Remove front, center, rear exhaust pipe and
muffler. (SOHC model)
, , and
6) Remove the center and rear exhaust pipes and (A) Select cable
muffler. (DOHC turbo model) (B) Plate ASSY
, and then remove the cable bracket.
7) Remove the heat shield cover. (If equipped)
(B) (A)
CS-00038
AT-00682
(A) Adjusting nuts
8) Remove the snap pin and washer from range se- (B) Cable bracket
lect lever.
11) Remove the select cable from plate assembly.
(A)
(D)
(B)
(C) (E)
CS-00036
(A) Range select lever
(B) Snap pin
(C) Select cable
(D) Clamp
(E) Washer
CS-26
SELECT CABLE
CONTROL SYSTEMS
B: INSTALLATION 7) Install the heat shield cover.
1) Install the select cable to plate assembly.
Tightening torque:
