Image preview - the first page of the document
>> Download 08. Reverse Check Cable documenatation <<
Text preview - extract from the document
REVERSE CHECK CABLE
CONTROL SYSTEMS
8. Reverse Check Cable 9) Remove the rear exhaust pipe and muffler.
,
2) Remove the gear shift knob. 10) Remove the crossmember.
REMOVAL, Console Box.> 11) Remove the snap pin and washer, and then
4) Remove the spring pin from slider. separate the reverse check cable from reverse
check lever.
(B)
(A)
(B)
(A)
CS-00225 (C)
CS-00220
(A) Slider
(B) Spring pin (A) Snap pin
(B) Washer
5) Remove the slider and spring. (C) Reverse check cable
12) Move the transmission to right side, and then
(A) remove the stay bolt and reverse check cable.
NOTE:
(B)
If the transmission is not moved, the stay bolt will
contact body and damage may occur.
(A)
CS-00226
(B)
(A) Slider
(B) Spring
6) Cut the band clip, and then separate the reverse
check cable from gear shift lever.
CS-00245
(A) Stay
(B) Stay bolt
CS-00227
7) Lift-up the vehicle.
8) Remove the under cover.
CS-45
REVERSE CHECK CABLE
CONTROL SYSTEMS
13) Raise the clip of stay, and then separate the B: INSTALLATION
stay and reverse check cable. 1) Adjust the length between end of cable plate and
reverse check cable to 84 mm (3.31 in), and then
tighten the lock nut.
(B) Tightening torque:
(A) 6 N ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
