Image preview - the first page of the document
>> Download 03. Select Lever documenatation <<
Text preview - extract from the document
SELECT LEVER
CONTROL SYSTEMS
3. Select Lever 10) Disconnect the connectors, then remove the
four bolts to take out the select lever assembly from
A: REMOVAL the body.
1) Set the vehicle on a lift.
2) Disconnect negative cable from battery.
3) Set the select lever to the "N" range.
4) Lift-up the vehicle.
5) Remove the rear exhaust pipe and muffler.
SOHC model
and
DOHC turbo model
CS-00018
and
1) Mount the select lever onto the vehicle body.
6) Remove the heat shield cover. (If equipped)
2) Tighten the four bolts to install the select lever to
the vehicle body, then connect connector.
Tightening torque:
13 N ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
