Image preview - the first page of the document
10. Transmission Mounting System


>> Download 10. Transmission Mounting System documenatation <<

Text preview - extract from the document
                            TRANSMISSION MOUNTING SYSTEM
AUTOMATIC TRANSMISSION

10.Transmission Mounting Sys-                          7) Remove the transmission rear crossmember.
   tem
A: REMOVAL
1. PITCHING STOPPER
1) Disconnect the ground cable from battery.
2) Remove the air cleaner case. (Non-turbo model)

3) Remove the intercooler. (Turbo model)                                                       AT-00024
                                                   8) Remove the rear cushion rubber.
4) Remove the pitching stopper.                        B: INSTALLATION
                                                       1. PITCHING STOPPER
                                                       1) Install the pitching stopper.
                                                       Tightening torque:
                                                         T1: 50 N
