Image preview - the first page of the document
17. Shift Solenoids, Duty Solenoids and ATF Temperature Sens


>> Download 17. Shift Solenoids, Duty Solenoids and ATF Temperature Sens documenatation <<

Text preview - extract from the document
  SHIFT SOLENOIDS, DUTY SOLENOIDS AND ATF TEMPERATURE SENSOR
                                                                                               AUTOMATIC TRANSMISSION

17.Shift Solenoids, Duty Sole-                                       7) Remove the solenoids and duty solenoids.
   noids and ATF Temperature                                                                         (C)         (D)

   Sensor                                                                            (A)       (B)
                                                                                                                       (E)
A: REMOVAL
1. SHIFT SOLENOIDS AND DUTY SOLE-
NOIDS
1) Lift-up the vehicle.
2) Clean the transmission exterior.                                                                                     (F)
3) Replace the gasket with a new one, and tighten                                                          (G)            AT-00859
the drain plug.
4) Drain the ATF completely.                                               (A)    Lock-up duty solenoid (Blue)
                                                                           (B)    Low clutch timing solenoid (Gray)
Tightening torque:
                                                                           (C)    Line pressure duty solenoid (Red)
  25 N
