Image preview - the first page of the document
24. Oil Charger Pipe


>> Download 24. Oil Charger Pipe documenatation <<

Text preview - extract from the document
                                          OIL CHARGER PIPE
                                                             AUTOMATIC TRANSMISSION

24.Oil Charger Pipe
A: REMOVAL
1) Remove the air cleaner case. (Non-turbo model)

2) Remove intercooler. (Turbo model)

3) Remove the oil charger pipe, and remove the O-
ring from the flange face.



         (A)




                              (B)
                                         AT-00808


       (A) Oil level gauge
       (B) Oil charger pipe

B: INSTALLATION
1) Install the oil charger pipe with new O-ring.
Tightening torque:
  41 N
