Image preview - the first page of the document



>> Download 26. Extension Case documenatation <<

Text preview - extract from the document

                                               EXTENSION CASE
                                                                                    AUTOMATIC TRANSMISSION

26.Extension Case                                            2) Install new gasket.
                                                             3) Install the extension case to the transmission
A: REMOVAL                                                   case.
1) Remove the transmission assembly.
2) Remove rear vehicle speed sensor.                           25 N
