Image preview - the first page of the document
27. Transfer Clutch


>> Download 27. Transfer Clutch documenatation <<

Text preview - extract from the document
                                        TRANSFER CLUTCH
                                                                               AUTOMATIC TRANSMISSION

27.Transfer Clutch                                     C: DISASSEMBLY
                                                       1) Remove the seal ring.
A: REMOVAL
1) Remove the transmission assembly from vehi-
cle.
2) Remove the extension case and remove the
transfer clutch.  and
B: INSTALLATION
1) Select the thrust needle bearing.
2) Install the transfer clutch assembly to the case.
                                                             (A) Seal ring
                                                             (B) Transfer clutch
             (A)
                                                       2) Using a press and ST, remove the ball bearing.
                                                       ST 498077600        REMOVER




       (B)

                                        AT-00125


      (A) Transfer clutch
      (B) Extension case
                                                                                              AT-00128
3) Tighten bolts to secure the case.
Tightening torque:                                     3) Remove the snap ring, and take out the pressure
  25 N
