Image preview - the first page of the document
28. Multi-plate Clutch


>> Download 28. Multi-plate Clutch documenatation <<

Text preview - extract from the document
                                         MULTI-PLATE CLUTCH
                                                                                    AUTOMATIC TRANSMISSION

28.Multi-plate Clutch                                       3) Using ST, measure height "B" from transmission
                                                            case joining edge to center differential clutch drum
A: REMOVAL                                                  edge.
Remove multi-plate clutch following the same in-            ST 398744300        GAUGE
structions as for the extension case.
B: INSTALLATION
Install multi-plate clutch following the same instruc-
tions as for the extension case.                                       B

C: INSPECTION
