Image preview - the first page of the document
29. Rear Drive Shaft


>> Download 29. Rear Drive Shaft documenatation <<

Text preview - extract from the document
                                            REAR DRIVE SHAFT
AUTOMATIC TRANSMISSION

29.Rear Drive Shaft                                        2) Using a press, remove the front and rear side
                                                           ball bearings and clutch hub.
A: REMOVAL
1) Remove transmission assembly.
                                                                                                 (C)
2) Remove rear wheel speed sensor and separate
extension case from transmission case.
3) Pull out the rear driveshaft from the center differ-
ential assembly.

                                                                                                        AT-00151
                                      (A)

                                                                 (A) Rear ball bearing
                                                                 (B) Rear driveshaft
                                                                 (C) Clutch hub

                                                           D: ASSEMBLY
                                                           Assemble in the reverse order of disassembly.
                                (B)                        NOTE:
                                            AT-00145
