Image preview - the first page of the document



>> Download 30. Reduction Driven Gear documenatation <<

Text preview - extract from the document

                                        REDUCTION DRIVEN GEAR
                                                                                       AUTOMATIC TRANSMISSION

30.Reduction Driven Gear                                       3) Remove the rear drive shaft.
A: REMOVAL                                                     4) Set the range select lever to "P".
                                                               5) Straighten the staked portion, and remove the
1. MPT MODEL                                                   lock nut.
1) Remove the transmission assembly from the ve-
hicle.
2) Remove rear vehicle speed sensor, and sepa-
rate the transmission case and extension case.

3) Set the range select lever to "P".
4) Straighten the staked portion, and remove the
lock nut.

                                    (B)                                                                       AT-00155

                                                               6) Using the ST1 and ST2, extract the reduction
                                                               driven gear.
                                          (A)                  ST1 499737000 PULLER
                                                               ST2 899524100 PULLER SET
                                                               7) Pull out the center differential assembly.
                                                               B: INSTALLATION
                                                AT-00153
                                                               1. MPT MODEL
      (A) Reduction driven gear                                1) Set the select lever to "P" range.
      (B) Reduction drive gear                                 2) Using a plastic hammer, install reduction driven
                                                               gear assembly and new washer, and tighten new
5) Using the ST1 and ST2, extract the reduction                drive pinion lock nut.
driven gear.
ST1 499737000 PULLER                                           Tightening torque:
ST2 899524100 PULLER SET                                         100 N
