Image preview - the first page of the document
>> Download 31. Reduction Drive Gear documenatation <<
Text preview - extract from the document
REDUCTION DRIVE GEAR
AUTOMATIC TRANSMISSION
31.Reduction Drive Gear C: DISASSEMBLY
1) Take out the seal rings.
A: REMOVAL
1) Remove the transmission assembly from the ve-
hicle.
2) Remove rear vehicle speed sensor, and sepa- (A)
rate the transmission case and extension case.
3) Remove the reduction driven gear.
4) Using ST, extract the reduction drive gear.
(B)
ST1 499737000 PULLER AT-00161
ST2 899524100 PULLER SET
(A) Seal rings
(A)
(B) Reduction drive shaft
2) Using ST, remove the ball bearing.
ST1
ST 498077600 REMOVER
ST
(A)
ST2
AT-00159
(A) Reduction drive gear
(B)
B: INSTALLATION
1) Install the reduction drive gear assembly. AT-00162
NOTE:
(A) Ball bearing
Insert it fully into position until the bearing shoulder
bottoms. (B) Reduction drive gear
3) Using a press, remove the reduction drive gear.
(A)
(A)
AT-00160
AT-00163
(A) Reduction drive gear
(A) Reduction drive gear
2) Install the reduction driven gear.
3) Combine the transmission case with the exten-
sion case, and install rear vehicle speed sensor.
4) Install the transmission assembly to the vehicle.
4AT-89
REDUCTION DRIVE GEAR
AUTOMATIC TRANSMISSION
D: ASSEMBLY
1) Press-fit the reduction drive gear to the shaft.
2) Press-fit a new ball bearing to the reduction drive
gear.
3) Apply vaseline to the outer surface of seal ring
and shaft groove.
4) Attach a new seal rings.
(A)
(B)
AT-00161
(A) Seal rings
(B) Reduction drive shaft
E: INSPECTION
