Image preview - the first page of the document
32. Center Differential Carrier


>> Download 32. Center Differential Carrier documenatation <<

Text preview - extract from the document
                                CENTER DIFFERENTIAL CARRIER
                                                                                AUTOMATIC TRANSMISSION

32.Center Differential Carrier                            C: DISASSEMBLY
                                                          1) Remove the seal rings.
A: REMOVAL
1) Remove the transmission assembly from vehi-
cle.
2) Remove the rear wheel speed sensor, and sep-
arate the extension case from the transmission
case.
3) Pull out the rear driveshaft.
4) Using the special tools, pull out the center differ-                         (A)
                                                                                                  AT-00166
ential carrier assembly.
ST1 499737000 PULLER                                            (A) Seal ring
ST2 899524100 PULLER SET
                                                          2) Using a press and the ST, remove the ball bear-
                                                          ing.
         ST1                                              ST 498077600        REMOVER




        ST2




                                          AT-00164

5) Pull out the shim(s) from transmission case.
B: INSTALLATION                                                                                     AT-00167

1) Install the center differential assembly with the      3) Remove the snap ring, and pull out the shaft
shim(s).                                                  from the center differential assembly.
NOTE:
Insert the center differential assembly and shim(s)                                         (A)
completely into the bearing shoulder bottom.




                                                                                              (B)

                                                                                                  AT-00168


                                                                (A) Snap ring
                                          AT-00165              (B) Shaft

2) Insert the rear driveshaft.
3) Connect the transmission case and extension
case, and install the rear wheel speed sensor.

4) Install the transmission assembly onto vehicle.



                                                     4AT-91
                                    CENTER DIFFERENTIAL CARRIER
AUTOMATIC TRANSMISSION

4) Remove the thrust washers, pinion gears, and
washers from the center differential assembly.
                                          (A)




                                            AT-00169


       (A) Pinion gear

5) Pull out the intermediate shaft and thrust bear-
ing.
D: ASSEMBLY
1) Install the thrust washer onto the intermediate
shaft.
2) Install thrust bearing onto the intermediate shaft.
3) Install the pinion gears and washers.
4) Insert the shaft into the center differential as-
sembly.
5) Install the snap ring.
6) Using a press, install a new ball bearing into the
center differential assembly.
ST 498077000           REMOVER
                                    (A)

                                                ST
              (B)




                                            AT-00170


       (A) Plate
       (B) Center differential carrier

7) Apply Vaseline onto the seal ring outer surface
and shaft grooves.
8) Install new seal rings.
