                                              PARKING PAWL
                                                                                AUTOMATIC TRANSMISSION

33.Parking Pawl                                           5) Install the transmission assembly to the vehicle.

1) Remove the transmission assembly from the ve-
hicle.                                    Make sure that the tab of the packing pole on the
2) Remove rear vehicle speed sensor and separate          reduction gear is not worn or otherwise damaged.
transmission case and extension case sections.

3) Remove the reduction drive gear. (MPT model)

4) Remove the center differential carrier. (VTD
model)
5) Remove the parking pawl, return spring and
shaft.


            (A)                   (B)




                                          AT-00171


       (A) Return spring
       (B) Parking pawl

B: INSTALLATION
1) Install the parking pawl, shaft and return spring.


            (A)                   (B)




                                          AT-00171


       (A) Return spring
       (B) Parking pawl

2) Install the reduction drive gear.
3) Install the center differential carrier. (VTD model)

4) Install the rear vehicle speed sensor and exten-
sion case.

                                                     4AT-93
