Image preview - the first page of the document
36. Drive Pinion Shaft


>> Download 36. Drive Pinion Shaft documenatation <<

Text preview - extract from the document
                                       DRIVE PINION SHAFT
AUTOMATIC TRANSMISSION

36.Drive Pinion Shaft                                   14) Remove the drive pinion shaft mounting bolt
                                                        and remove the drive shaft assembly from oil pump
A: REMOVAL                                              housing.
1) Remove the transmission assembly from vehi-
cle.
2) Extract the torque converter clutch assembly.

3) Remove the input shaft.



                                                                                                   AT-01252

                                                        B: INSTALLATION
                                                        1) Assemble the drive pinion assembly to the oil
                                                        pump housing.
