Image preview - the first page of the document
>> Download 37. Front Differential documenatation <<
Text preview - extract from the document
FRONT DIFFERENTIAL
AUTOMATIC TRANSMISSION
37.Front Differential B: INSTALLATION
1) Install the differential assembly to the case, pay-
A: REMOVAL ing special attention not to damage the inside of the
1) Remove the transmission assembly from the ve- case (particularly, the differential side retainer con-
hicle.
2) Extract the torque converter clutch assembly. (A)
3) Remove the input shaft.
AT-00215
(A) Differential assembly
2) Install the O-rings from left and right side retain-
AT-00114 er.
3) Using ST, install the side retainers.
connector and disconnect it from stay. ST 499787000 WRENCH ASSY
5) Disconnect the inhibitor switch from stay. 4) Adjust the front differential backlash.
REMOVAL, Oil Charger Pipe.> 5) Install the lock plate.
7) Remove the oil cooler inlet and outlet pipes.
