Image preview - the first page of the document



>> Download 04. Electrical Components Location documenatation <<

Text preview - extract from the document

                            ELECTRICAL COMPONENTS LOCATION
                                                                            AUTOMATIC TRANSMISSION (DIAGNOSTICS)

4. Electrical Components Location
A: LOCATION
1. CONTROL MODULE

                                        (1)




                                       (3)          (2)    (4)
                                                                                                                 AT-01132


 (1)   Engine control module (ECM)            (3)     Transmission control module   (4)   Data link connector
 (2)   AT OIL TEMP warning light (AT                  (TCM)
       diagnostic indicator light)




           (1)




                                                                                                  (2)

                                                          AT-00323                                              AT-00853




                              (3 )                                                         (4)




                                                          AT-00416                                              AT-00417




                                                                 4AT-7
                             ELECTRICAL COMPONENTS LOCATION
AUTOMATIC TRANSMISSION (DIAGNOSTICS)

2. SENSOR


                                          (1)   (7)         (3)         (6)




                                                      (5)         (2)         (4)
                                                                                                                   AT-00818


 (1)   Throttle position sensor     (4)    Rear vehicle speed sensor                (6)   ATF temperature sensor
 (2)   Front vehicle speed sensor   (5)    Torque converter turbine speed           (7)   Dropping resistor (Non-turbo
 (3)   Inhibitor switch                    sensor                                         model)




                                                      4AT-8
                      ELECTRICAL COMPONENTS LOCATION
                                                               AUTOMATIC TRANSMISSION (DIAGNOSTICS)

                                                       Non-turbo model


                                                                 (2)




                         (1)

                                                                                      (4)


                                           AT-00328                                          AT-00329
Turbo model



          (2)




                               (4)

                                                                                (3)
                                           AT-01133                                          AT-00330




                (5)


                                                                                            (6)




                                           AT-00331                                          AT-00332




                                     (7)




                                           AT-00820
                                            AT-00820




                                                 4AT-9
                                ELECTRICAL COMPONENTS LOCATION
AUTOMATIC TRANSMISSION (DIAGNOSTICS)

3. SOLENOID

                                                                               (6)    (7)




                                                               (5)       (4)    (3)     (2)   (1)     (8)
                                                                                                                                        AT-00333


 (1)   Solenoid 1                                  (4)     Low clutch timing solenoid               (7)     2-4 brake timing solenoid
 (2)   Solenoid 2                                  (5)     Lock-up duty solenoid                    (8)     Transfer duty solenoid
 (3)   Line pressure duty solenoid                 (6)     2-4 brake duty solenoid




                   (5)    (4)   (3)    (2)
                                                     (1)




                                 (6)         (7)                                      (8)
                                                              AT-00334                                                              AT-00335




                                                                     4AT-10
