Image preview - the first page of the document
06. Switches and Harness


>> Download 06. Switches and Harness documenatation <<

Text preview - extract from the document
                                         SWITCHES AND HARNESS
                                                               MANUAL TRANSMISSION AND DIFFERENTIAL

6. Switches and Harness                                   6) Remove the back-up light switch and neutral po-
                                                          sition switch with harness.
A: REMOVAL
1. BACK-UP LIGHT AND NEUTRAL POSI-                                                            (A)
TION SWITCH
1) Disconnect the ground cable from battery.
2) Remove the air intake duct and cleaner case.
(Non-turbo model)  and
3) Remove the intercooler. (Turbo model)                                                                MT-00106

4) Disconnect the connector of back-up light switch
and neutral position switch.                                     (A) Neutral switch (Brown)
