Image preview - the first page of the document
02. Transmission Gear Oil


>> Download 02. Transmission Gear Oil documenatation <<

Text preview - extract from the document
                                      TRANSMISSION GEAR OIL
                                                                MANUAL TRANSMISSION AND DIFFERENTIAL

2. Transmission Gear Oil                                   B: REPLACEMENT
                                                           1) Pull out the oil level gauge.
A: INSPECTION                                              2) Lift-up the vehicle.
1) Park the vehicle on a level surface.                    3) Drain the transmission gear oil completely.
2) Turn the ignition switch to OFF, and then wait
until the engine cools.                                    CAUTION:
3) Remove the oil level gauge and wipe it clean.           Directly after the engine has been running, the
4) Reinsert the level gauge all the way. Be sure the       transmission gear oil is hot. Be careful not to
level gauge is correctly inserted and in the proper        burn yourself.
direction.                                                 NOTE:
5) Pull out the oil level gauge again and check the        Tighten the transmission gear oil drain plug after
oil level on it. If it is below the lower level, add oil   draining the transmission gear oil.
through the oil level gauge hole to bring the level up     Tightening torque:
to the upper level.
                                                             69 N
