Image preview - the first page of the document



>> Download 14. Transmission Case documenatation <<

Text preview - extract from the document

                                        TRANSMISSION CASE
                                                              MANUAL TRANSMISSION AND DIFFERENTIAL

14.Transmission Case                                     7) Separate the transmission case into right and
                                                         left cases by loosening the coupling bolts and nuts.
A: REMOVAL
1) Remove the manual transmission assembly
from vehicle.
2) Remove the clutch release lever.
3) Remove the transfer case with extension case
assembly.
4) Remove the bearing mounting bolts.
                                                                                                   MT-00160

                                                         8) Remove the drive pinion shaft assembly from left
                                                         side transmission case.
                                                         NOTE:
                                                         Use a hammer handle, etc. to remove if too tight.
                                                                                             (A)
                                                                     (B)



                                         MT-00158

5) Remove the main shaft rear plate.
               (A)



                                                                                                   MT-00161


                                                                (A) Main shaft assembly
                                                                (B) Drive pinion shaft assembly

                                                         9) Remove the main shaft assembly.
                                                         10) Remove the differential assembly.
                                         MT-00159
                                                         NOTE:
       (A) Main shaft rear plate
