Image preview - the first page of the document



>> Download 17. Front Differential Assembly documenatation <<

Text preview - extract from the document

                              FRONT DIFFERENTIAL ASSEMBLY
MANUAL TRANSMISSION AND DIFFERENTIAL

17.Front Differential Assembly                          B: INSTALLATION
                                                        1) Install the differential side retainers using ST.
A: REMOVAL                                              ST 499787000           WRENCH ASSY
1) Remove the manual transmission assembly              2) Install the bearing outer race to transmission
from vehicle.                                  3) Install the differential assembly.
2) Remove the transfer case with extension case
assembly.
