Image preview - the first page of the document



>> Download 18. Speedometer Gear documenatation <<

Text preview - extract from the document

                                     SPEEDOMETER GEAR
MANUAL TRANSMISSION AND DIFFERENTIAL

18.Speedometer Gear                                  B: INSTALLATION
                                                     1) Install the washer and speedometer shaft, and
A: REMOVAL                                           press fit the oil seal with ST.
1) Remove the manual transmission assembly
from vehicle.                               Use a new oil seal, if it has been removed.
2) Remove the back-up light switch and neutral po-   ST 899824100 or 499827000            PRESS
sition switch.                                      37, INSTALLATION, Vehicle Speed Sensor.>
3) Remove the transfer case with extension case      3) Install the speedometer driven gear and snap
assembly.                    NOTE:
4) Remove the transmission case.
5) Remove the vehicle speed sensor.
6) Remove the outer snap ring and pull out speed-
ometer driven gear. Next, remove the oil seal,
speedometer shaft and washer.

                                                                             (A)   (B)




                                                                                             MT-00301


                                                            (A) Outer snap ring
                       (A)   (B)
                                                            (B) Speedometer driven gear

                                                     4) Install the transmission case.
                                                     5) Install the transfer case with extension case as-
      (A) Outer snap ring                            sembly.
                                                     6) Install the back-up light switch and neutral posi-
                                                     tion switch.
                                                     7) Install the manual transmission assembly to ve-
                                                     hicle.
                                                     C: INSPECTION
                                                     Check the speedometer gear, oil seal and speed-
                                                     ometer shaft for damage. Replace if damaged.




                                                 5MT-76
