Image preview - the first page of the document
10. Transfer Drive Gear


>> Download 10. Transfer Drive Gear documenatation <<

Text preview - extract from the document
                                      TRANSFER DRIVE GEAR
                                                             MANUAL TRANSMISSION AND DIFFERENTIAL

10.Transfer Drive Gear                                  C: DISASSEMBLY
                                                        1) Remove the snap ring.
A: REMOVAL
1) Remove the manual transmission assembly
from vehicle.
2) Remove the back-up light switch and neutral po-
sition switch.
3) Remove the transfer case with extension case
assembly.
4) Remove the extension case assembly.                                                           MT-00135
5) Remove the transfer driven gear.
6) Remove the transfer drive gear.                      2) Remove the ball bearing.




                                                                                                 MT-00136
                                        MT-00133

B: INSTALLATION                                         D: ASSEMBLY
1) Install the transfer drive gear.                     1) Set the ST applying to inner race of bearing and
                                                        install to drive shaft.
Tightening torque:                                      ST 398177700            INSTALLER
  26 N
