Image preview - the first page of the document



>> Download 12. Center Differential documenatation <<

Text preview - extract from the document

                                       CENTER DIFFERENTIAL
                                                              MANUAL TRANSMISSION AND DIFFERENTIAL

12.Center Differential                                   C: DISASSEMBLY
A: REMOVAL                                               NOTE:
1) Remove the manual transmission assembly               Do not disassemble the center differential because
from vehicle.                                   Remove the ball bearing using ST.
2) Remove the transfer case with extension case          NOTE:
assembly.                        ST 498077300        CENTER DIFFERENTIAL
3) Remove the extension case assembly.
4) Remove the transfer driven gear.                                     ST
5) Remove the center differential.
B: INSTALLATION
1) Install the center differential into transfer case.
2) Install the transfer driven gear.
3) Install the extension case assembly.                                   D: ASSEMBLY
4) Install the transfer case with extension case as-     Install the ball bearing to center differential assem-
sembly.
5) Install the back-up light switch and neutral posi-    NOTE:
tion switch.                                             US ton, 1.0 Imp ton).
6) Install the manual transmission assembly to ve-
hicle.




                                                                                              (A)

                                                                                                    MT-00148


                                                                (A) Ball bearing

                                                         E: INSPECTION
                                                         1) Bearings
                                                         Replace the bearings in the following cases:
