Image preview - the first page of the document



>> Download 20. Shifter Fork and Rod documenatation <<

Text preview - extract from the document

                                      SHIFTER FORK AND ROD
                                                              MANUAL TRANSMISSION AND DIFFERENTIAL

20.Shifter Fork and Rod                                  10) Drive out the straight pin, and pull out 3-4 fork
                                                         rod and shifter fork.
A: REMOVAL                                               NOTE:
1) Remove the manual transmission assembly               When removing the rod, keep other rods in neutral.
from vehicle.                                   ward the inside of case so that it does not hit
2) Remove the back-up light switch and neutral po-       against the case.
sition switch.                                                             (C)
3) Remove the transfer case with extension case
assembly.
4) Remove the transmission case.
5) Remove the drive pinion shaft assembly.
6) Remove the main shaft assembly.                                       (A)       (B)            MT-00310
                                                           (A) Straight pin
7) Remove the differential assembly.
                                                                (C) Shifter fork
8) Drive out the straight pin with ST, and 5th shifter
fork.                                                    11) Drive out the straight pin, and pull out 1-2 fork
ST 398791700          STRAIGHT PIN REMOVER               rod and shifter fork.
                                                         12) Remove the outer snap ring, and pull out the
                                                         reverse shifter rod arm from reverse fork rod. Then
                                                         take out the ball, spring and interlock plunger from
                                                         rod.
                                                         And then remove the rod.
                                                         NOTE:
                                                         When pulling out the reverse shifter rod arm, be
                                                         careful not to let the ball pop out of arm.
                                                         13) Remove the reverse shifter lever.
       (B)   (A)                         MT-00309


       (A) Straight pin
       (B) 5th shifter fork

9) Remove the plugs, springs and checking balls.




                                                    5MT-79
                                        SHIFTER FORK AND ROD
MANUAL TRANSMISSION AND DIFFERENTIAL

B: INSTALLATION                                             9) Position the balls, checking ball springs and new
1) Install the reverse arm fork spring, ball and inter-     gaskets into 3-4 and 1-2 rod holes, and install
lock plunger to reverse fork rod arm. Insert the re-        plugs.
verse fork rod into hole in reverse fork rod arm, and
hold it with outer snap ring using ST.                            (B)
NOTE:
Apply grease to plunger to prevent it from falling.
ST 399411700           ACCENT BALL INSTALLER
2) Position the ball, spring and new gasket in re-
verse shifter rod hole, on left side transmission
case, and tighten the checking ball plug.
3) Install the 1-2 fork rod into 1-2 shifter fork via the
                                                                   (A)
hole on the rear of transmission case.                                   (C)                         MT-00311
4) Align the holes in rod and fork, and new drive
straight pin into these holes using ST.                            (A) 5th shifter fork
NOTE:                                                              (B) Reverse fork rod
