Image preview - the first page of the document
04. Vehicle Speed Sensor


>> Download 04. Vehicle Speed Sensor documenatation <<

Text preview - extract from the document
                                     VEHICLE SPEED SENSOR
MANUAL TRANSMISSION AND DIFFERENTIAL

4. Vehicle Speed Sensor
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the intercooler.
3) Disconnect the vehicle speed sensor connector.




                                         MT-00452

4) Remove the vehicle speed sensor.
B: INSTALLATION
1) Align the tip end of vehicle speed sensor key
with key groove on the end of speedometer shaft,
and then install it.
Tightening torque:
  5.9 N
