Image preview - the first page of the document
>> Download 06. Manual Transmission Assembly documenatation <<
Text preview - extract from the document
MANUAL TRANSMISSION ASSEMBLY
MANUAL TRANSMISSION AND DIFFERENTIAL
6. Manual Transmission As- 8) Disconnect the ground cable at upper side of
transmission case and body.
sembly
A: REMOVAL
1) Set the vehicle on a lift, and then open the front
hood and support it with hood stay.
NOTE:
Set the hood stay to its specified hole.
2) Remove the front wheel.
3) Disconnect the ground cable from battery.
4) Remove the intercooler assembly. MT-00456
5) Lift-up the vehicle, and then remove the under
cover.
6) Remove the steering universal joint.
7) Lower the vehicle and disconnect the connector
located on upper side of transmission.
(A)
MT-00457
(B)
9) Remove the starter assembly.
10) Remove the clutch operating cylinder.
NOTE:
MT-00455
Hang the removed operating cylinder with a wire,
etc.
(A) Transmission connector
(B) Vehicle speed sensor connector
MT-00458
11) Remove the clutch release shaft.
(1) Remove the plug with hexagon wrench.
(2) Install a 6 mm (0.24 in) bolt to the release
shaft, then pull out the release shaft.
(3) Lift up the release fork, and then remove it
from the release bearing claw. Pull it to the en-
gine side and set it free.
12) Remove the pitching stopper, and then remove
the pitching stopper bracket.
6MT-35
MANUAL TRANSMISSION ASSEMBLY
MANUAL TRANSMISSION AND DIFFERENTIAL
13) Set the ST. 18) Using the ST, remove the spring pin of front
ST 41099AA000 ENGINE SUPPORT drive shaft.
ST 398791700 REMOVER
NOTE:
Do not reuse the spring pin.
ST
MT-00459
14) Remove the center and rear exhaust pipe and
muffler. , , 19) Remove the front drive shaft.
15) Remove the propeller shaft. sion, then remove the front crossmember and rear
crossmember.
16) Remove the front stabilizer bolt.
MT-00454
MT-00076
21) Move the transmission to right side, then re-
17) Remove the ball joint of transverse link from
move the joint COMPL, stay bolt and reverse check
housing.
cable.
NOTE:
If the transmission is not moved, the joint COMPL
and stay bolt will contact body and damage may
occur.
(C)
(A)
MT-00460 (B)
MT-00886
(A) Joint COMPL bolt
(B) Stay bolt
(C) Reverse check cable
6MT-36
MANUAL TRANSMISSION ASSEMBLY
MANUAL TRANSMISSION AND DIFFERENTIAL
22) Remove the fixing bolt of engine and transmis- 3) Move the transmission to the right side, then in-
sion, then remove the transmission from vehicle. stall the joint COMPL bolt, stay bolt and reverse
NOTE: check cable.
