Image preview - the first page of the document
03. Oil Seal


>> Download 03. Oil Seal documenatation <<

Text preview - extract from the document
                                                         OIL SEAL
                                                                    MANUAL TRANSMISSION AND DIFFERENTIAL

3. Oil Seal                                                   6) Using the ST, install the oil seal.
                                                              ST 498057300         INSTALLER
A: INSPECTION
Inspect for oil leakage from the oil seal. Replace
the oil seal if the lips is deformed, hardened, dam-
aged, worn or defective if any.
B: REPLACEMENT
1) Clean the transmission exterior.
2) Drain the gear oil completely.
NOTE:
