Image preview - the first page of the document
>> Download 15. Transfer Driven Gear documenatation <<
Text preview - extract from the document
TRANSFER DRIVEN GEAR
MANUAL TRANSMISSION AND DIFFERENTIAL
15.Transfer Driven Gear C: DISASSEMBLY
1) Using the ST, remove the roller bearing of exten-
A: REMOVAL sion case side.
1) Remove the manual transmission assembly ST 498515700 REMOVER
from vehicle.
2) Prepare the transmission for overhaul. ST
3) Remove the extension case.
4) Remove the transfer driven gear.
MT-00511
2) Using the ST, remove the roller bearing of trans-
mission case side.
ST1 899858600 REMOVER
ST2 899864100 REMOVER
MT-00951
ST2
B: INSTALLATION ST1
1) Install the transfer driven gear.
MT-00512
D: ASSEMBLY
1) Using the ST, install the roller bearing of exten-
sion case side.
MT-00951 ST1 398177700 INSTALLER
ST2 899864100 REMOVER
2) If the bearing or transfer driven gear is replaced,
select the transfer driven thrust washer. Do not apply pressure in excess of 10 kN (1 ton,
3) Install the extension case.
4) Install the manual transmission assembly to ve-
ST2
hicle.
(A) ST1
MT-00513
(A) Roller bearing
6MT-58
TRANSFER DRIVEN GEAR
MANUAL TRANSMISSION AND DIFFERENTIAL
2) Using the ST, install the roller bearing of trans-
mission case side.
ST 499757002 INSTALLER
CAUTION:
Do not apply pressure in excess of 10 kN (1 ton,
1.1 US ton, 1.0 Imp ton).
ST
(A)
MT-00514
(A) Roller bearing
E: INSPECTION
1) Bearings
Replace the bearing in following cases.
