Text preview - extract from the document
OIL PUMP
MANUAL TRANSMISSION AND DIFFERENTIAL
17.Oil Pump ST2 399863600 PLIERS
A: REMOVAL
1) Remove the manual transmission assembly
ST2
from vehicle.
2) Prepare the transmission for overhaul.
3) Remove the extension case. ST1
4) Remove the transfer driven gear. MT-00486
5) Remove the center differential. spring pin.
6) Remove the oil guide.
(A)
(A)
(B)
MT-00487
MT-00953
(A) Striking rod
(A) Oil guide
(B) Spring pin
7) Remove the snap ring. 10) Remove the selector arm No. 2 and shifter arm.
(A)
(B) (A)
(B)
MT-00485
MT-00976
(A) Snap ring
(A) Selector arm No. 2
(B) Support
(B) Shifter arm
8) Using the ST, remove the neutral set spring and
support.
ST1 18756AA000 CLAW
6MT-61
OIL PUMP
MANUAL TRANSMISSION AND DIFFERENTIAL
11) Remove the oil pump shaft assembly and plate. B: INSTALLATION
NOTE: 1) Apply oil to the outer periphery of outer rotor,
Remove the bolts using ST, because tool may then install to transmission case.
break if general tool is used.
ST 18663AA000 SOCKET
(B)
(A)
(B) (A)
MT-00523
MT-00521 (A) Outer rotor
(B) Inner rotor
(A) Oil pump shaft assembly
2) Install the thrust washer to main shaft part.
(B) Plate
3) Install the oil pump cover assembly.
12) Remove the oil pump cover assembly. Tightening torque:
