Image preview - the first page of the document
>> Download 24. Speedometer Gear documenatation <<
Text preview - extract from the document
SPEEDOMETER GEAR
MANUAL TRANSMISSION AND DIFFERENTIAL
24.Speedometer Gear 15) Remove the oil seal, speedometer shaft and
washer.
A: REMOVAL
1) Remove the manual transmission assembly
from vehicle. (A)
2) Prepare the transmission for overhaul.
3) Remove the oil pipe, neutral position switch, (C)
back-up light switch and harness. , , MT-00677
4) Remove the extension case. (A) Washer
5) Remove the transfer driven gear. (C) Oil seal
6) Remove the center differential. 16) Remove the snap ring from speedometer shaft.
7) Remove the oil pump. 1) Install the oil seal, washer and snap ring to
8) Remove the transmission case. 2) Insert the speedometer shaft. Using the ST,
9) Remove each gear assembly. ST 899824100 or 499827000PRESS
10) Remove the drive pinion shaft assembly.
11) Remove the front differential assembly.
12) Remove the vehicle speed sensor.
13) Remove the snap ring, and then remove the
speedometer driven gear.
MT-00678
NOTE:
