22. Drive Pinion Shaft Assembly


>> Download 22. Drive Pinion Shaft Assembly documenatation <<

Text preview - extract from the document
                              DRIVE PINION SHAFT ASSEMBLY
                                                            MANUAL TRANSMISSION AND DIFFERENTIAL

22.Drive Pinion Shaft Assembly                        B: INSTALLATION
                                                      1) Completely remove the remaining gasket on
A: REMOVAL                                            drive plate and clutch housing.
1) Remove the manual transmission assembly            2) Apply liquid gasket to the clutch housing.
from vehicle.                                Liquid gasket:
2) Prepare the transmission for overhaul.
3) Remove the oil pipe, neutral position switch,
back-up light switch and harness. , ,
4) Remove the extension case.
5) Remove the transfer driven gear.
                                                                                                MT-00532
6) Remove the center differential.                         3) Install each gear assembly.
MOVAL, Oil Pump.>                                     4) Install the transmission case.
65, REMOVAL, Transmission Case.>                      5) Install the oil pump.
REMOVAL, Main Shaft Assembly.>                        6) Install the center differential.
                                                      7) Install the transfer driven gear.
                                                      8) Install the extension case.
                                                      9) Install the oil pipe, neutral position switch, back-
                                                      up light switch and harness. , ,
                                       MT-00640
                                                      10) Install the manual transmission assembly to ve-
                                                      hicle.




                                                  6MT-97
                               DRIVE PINION SHAFT ASSEMBLY
MANUAL TRANSMISSION AND DIFFERENTIAL

C: DISASSEMBLY                                           6) Using the ST, remove the taper roller bearing as-
                                                         sembly.
NOTE:                                                    ST 18723AA000 REMOVER
Replace the drive pinion shaft as a set with hypoid
driven gear.
1) Remove the pipe and oil chamber.
                                                                                                ST


          (B)                       (A)




                                                                                                     MT-00644

                                                         D: ASSEMBLY
                                          MT-00641       1) Using the ST, measure dimension A of drive pin-
                                                         ion.
       (A) Pipe
                                                         NOTE:
       (B) Oil chamber                                   Note dimension A for selection of drive pinion shim.
2) Remove the drive pinion shaft and shim from           ST 398643600        GAUGE
adapter plate.




                                                                                  ST

                                                                                            A        MT-00645
                                          MT-00642
                                                         2) Install the inner bearing inner race to drive pinion
3) Secure the ST on workbench.                           shaft using ST and press.
ST 18664AA000 BASE                                       ST 18723AA000 REMOVER
4) Lift the caulking of lock nut.                        CAUTION:
5) Install the ST3 to lock nut, then set drive pinion    Do not apply pressure in excess of 40 kN (4.0
shaft to ST. Remove the lock nut and washer.             ton, 4.4 US ton, 3.9 lmp ton).
ST1 18667AA000 HOLDER
ST2 18664AA000 BASE
ST3 18621AA000 ADAPTER WRENCH

                                                                                                ST
           ST3
                                      ST2




                ST1                                                                                  MT-00646



                                          MT-00643




                                                     6MT-98
                               DRIVE PINION SHAFT ASSEMBLY
                                                               MANUAL TRANSMISSION AND DIFFERENTIAL

3) Install the retainer and outer bearing inner race
