Image preview - the first page of the document



>> Download 04. Release Bearing and Lever documenatation <<

Text preview - extract from the document

                                  RELEASE BEARING AND LEVER
                                                                                           CLUTCH SYSTEM

4. Release Bearing and Lever                            2. TURBO MODEL
A: REMOVAL                                              1) Remove the transmission assembly from vehicle
                                                        body.
1. NON-TURBO MODEL                                      5MT:

body.

2) Remove the two clips from clutch release lever
and remove the release bearing.                         2) Remove the clutch release lever from transmis-
                                                        sion.
CAUTION:                                                3) Put the clutch release bearing in engine side.
Be careful not to deform clips.                         4) Remove the clutch release bearing from the
3) Remove the release lever seal.                       clutch cover using flat-type screwdriver.

                                                                                              (A)




                     (A)




                      (B)

                                         CL-00023                                              CL-00025


       (A) Clutch release lever                               (A) Clutch release bearing
       (B) Release lever seal

4) Remove the release lever retainer spring from
release lever pivot with a screwdriver by accessing
it through clutch housing release lever hole. Then
remove the release lever.


                   (B)




                                   (A)

                                         CL-00024


       (A) Clutch release lever
       (B) Screwdriver




                                                    CL-15
                                  RELEASE BEARING AND LEVER
CLUTCH SYSTEM

B: INSTALLATION                                           2. TURBO MODEL
1. NON-TURBO MODEL                                        1) Install the release bearing on transmission.
                                                          2) Insert the release fork into release bearing tab.
NOTE:
Before or during assembling, lubricate the following                                         (A)
points with a light coat of grease.
