Image preview - the first page of the document



>> Download 06. Master Cylinder documenatation <<

Text preview - extract from the document

                                        MASTER CYLINDER
CLUTCH SYSTEM

6. Master Cylinder                                     B: INSTALLATION
                                                       1) Install the master cylinder to body, and install the
A: REMOVAL                                             clutch pipe to master cylinder.
1) Thoroughly drain the brake fluid from reservoir
tank.                                                  NOTE:
2) Remove the snap pin, clevis pin and separate        Check that the pipe is routed properly.
the push rod of master cylinder from clutch pedal.     Tightening torque:
                                                         T1: 15 N
