Image preview - the first page of the document



>> Download 11. Clutch Switch documenatation <<

Text preview - extract from the document

                                            CLUTCH SWITCH
CLUTCH SYSTEM

11.Clutch Switch                                         2. CLUTCH SWITCH (STARTER INTER-
                                                         LOCK)
A: REMOVAL
                                                         1) Fully depress the clutch pedal.
1) Disconnect the ground cable from battery.
2) Remove the instrument panel lower cover.              2) Install the clutch pedal plate and clutch pedal so
                                                         that the gap between them is 3 -- 3.5 mm (0.12 --
3) Disconnect the connector from clutch switch.
                                                         0.14 in), and then tighten the lock nut.
4) Remove the clutch switch.
                                                         Tightening torque:
B: INSTALLATION                                            8 N
