Image preview - the first page of the document



>> Download 07. Front Crossmember documenatation <<

Text preview - extract from the document

                                    FRONT CROSSMEMBER
FRONT SUSPENSION

7. Front Crossmember                                 B: INSTALLATION
                                                     1) Install in the reverse order of removal.
A: REMOVAL
1) Disconnect the ground cable from battery.         NOTE:
2) Lift-up the vehicle, and then remove the front    Always tighten the bushing when tires are in full
wheels.                                              contact with the ground and vehicle is curb weight.
3) Remove the sub frame.                             Tightening torque:
4) Remove both the stabilizer and jack-up plate.        Transverse link bushing to crossmember:
                                                           125 N
