Image preview - the first page of the document



>> Download 08. Sub Frame documenatation <<

Text preview - extract from the document

                                                                 SUB FRAME
                                                                                                             FRONT SUSPENSION

8. Sub Frame                                                           B: INSTALLATION
                                                                       Install in the reverse order of removal.
A: REMOVAL
1) Lift-up the vehicle.                                                NOTE:
2) Remove the under cover.                                             Replace the M12 bolt with a new one.
3) Remove the bolt cover.                                              Tightening torque:
                                                                         T1: 34 N
