Image preview - the first page of the document
09. Front Support Arm


>> Download 09. Front Support Arm documenatation <<

Text preview - extract from the document
                                       FRONT SUPPORT ARM
                                                              FRONT SUSPENSION

9. Front Support Arm
A: REMOVAL
1) Set the vehicle on a lift.
2) Lift-up the vehicle.
3) Remove the under cover.
4) Remove the four bolts and jack-up plate.




                                           FS-00075

5) Remove the two nuts at both ends of arm re-
spectively.




                                           FS-00076

B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  Front support arm to crossmember:
    30 N
