Image preview - the first page of the document
>> Download 04. Rear Trailing Link documenatation <<
Text preview - extract from the document
REAR TRAILING LINK
REAR SUSPENSION
4. Rear Trailing Link C: DISASSEMBLY
A: REMOVAL 1. FRONT BUSHING
1) Loosen the rear wheel nuts. Using the ST, press the front bushing out of place.
2) Lift-up the vehicle, and then remove the rear ST 927720000 INSTALLER & REMOVER
wheels. SET
3) Remove both the rear parking brake clamp and
ABS wheel speed sensor harness. (1)
4) Remove the bolt which secures the trailing link to
trailing link bracket.
(2) ST
RS-00013
(1) Trailing link
5) Remove the bolt which secures the trailing link to
rear housing.
B: INSTALLATION
1) Install in the reverse order of removal. RS-00014
2) Always tighten the bushing location when tires
are in full contact with the ground and the vehicle is (1) Press
at curb weight condition.
(2) Trailing link
NOTE:
Check the wheel alignment and adjust if necessary.
RS-10
REAR TRAILING LINK
REAR SUSPENSION
2. REAR BUSHING D: ASSEMBLY
1) Remove the housing.
2) Using the ST, press the rear bushing out of Using the ST, press the bushing into trailing link.
place. ST 927720000 INSTALLER & REMOVER
ST 927730000 INSTALLER & REMOVER SET
SET CAUTION:
Turn the ST plunger upside down and press it
until the plunger end surface contacts the trail-
ing link end surface.
(1)
(2) ST
(3)
RS-00015
(1) Press
(2) Housing RS-00017
(1) Press
(2) Front bushing
(3) Trailing link
CAUTION:
Install the front bushing in the proper direction,
as shown in the figure.
(2)
(1)
RS-00110
(1) Front
