Image preview - the first page of the document
>> Download 01. General Description documenatation <<
Text preview - extract from the document
GENERAL DESCRIPTION
DRIVE SHAFT SYSTEM
1. General Description
A: SPECIFICATIONS
1. PROPELLER SHAFT
Model Non-turbo Turbo (except STi) STi
Propeller shaft type UJ DOJ UJ
Front propeller shaft Joint-to-joint length: L1 AT 584 (22.99) 579 (22.79) --
mm (in) MT 643 (25.32) 638 (25.12) 574 (22.60)
Rear propeller shaft Joint-to-joint length: L2 mm (in) 708 (27.87) 713 (28.07) 706 (27.80)
D1 63.5 (2.500) 70 (2.756)
Outer diameter of tube: mm (in)
D2 57.0 (2.244)
(A)
D1 D2
L1 L2
(B)
D1 D2
L1 L2
DS-00001
(A) UJ type (B) DOJ type
DS-2
GENERAL DESCRIPTION
DRIVE SHAFT SYSTEM
2. FRONT DRIVE SHAFT ASSEMBLY
Axle diameter D
Model Type of drive shaft Axle length L (mm)
(mm)
Non-turbo, Turbo AT EBJ87+SFJ82 26 (1.02) 325
Sedan Turbo MT (except STi) EBJ87+SFJ82 28 (1.10) 325
Turbo MT (STi) BJ92+DOJ87 28 (1.10) 250
Non-turbo, Turbo AT EBJ87+SFJ82 26 (1.02) 314
Wagon
Turbo MT EBJ87+SFJ82 28 (1.10) 314
(D)
(A) (C)
(D)
(B)
(C)
DS-00199
(A) EBJ87+SFJ82 (C) Axle diameter (D) Axle length
(B) BJ92+DOJ87
DS-3
GENERAL DESCRIPTION
DRIVE SHAFT SYSTEM
3. REAR DRIVE SHAFT ASSEMBLY
No. of identification Axle diameter
Type of drive shaft assembly Model Axle length (mm)
protrusion on shaft (mm)
EBJ82+DOJ82 RH 2 (Two) 363 24
Sedan turbo
EBJ82+DOJ82 LH 1 (One) 353 24
BJ79+DOJ79 RH 2 (Two) 368 23
Sedan Non-turbo
BJ79+DOJ79 LH 1 (One) 358 23
EBJ82+DOJ82 RH 2 (Two) 353 24
Wagon turbo
EBJ82+DOJ82 LH 1 (One) 343 24
BJ79+DOJ79 RH 2 (Two) 358 23
Wagon Non-turbo
BJ79+DOJ79 LH 1 (One) 348 23
BJ87+DOJ87 STi 1 (One) 295.2 25
(1)
(3)
(2)
DS-00224
(1) Identification protrusion (2) Axle length (3) Axle diameter
DS-4
GENERAL DESCRIPTION
DRIVE SHAFT SYSTEM
B: COMPONENT
1. PROPELLER SHAFT
(1)
(2)
T2
(3)
T2
T1
DS-00225
(1) Propeller shaft (DOJ type) (3) Rear differential Tightening torque: N◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
