Image preview - the first page of the document
>> Download 03. Front Axle documenatation <<
Text preview - extract from the document
FRONT AXLE
DRIVE SHAFT SYSTEM
3. Front Axle 6) Remove the disc rotor from hub.
NOTE:
A: REMOVAL If the disc rotor seizes up within hub, drive disc rotor
1) Lift-up the vehicle and remove the front wheels. out by installing an 8-mm bolt in screw hole on ro-
2) Unlock the axle nut. tor.
DS-00038
DS-00041
3) Remove the axle nut using a socket wrench
7) Remove the cotter pin and castle nut which se-
while depressing the brake pedal.
cure tie-rod end to housing knuckle arm.
CAUTION:
Remove the axle nut with vehicle weight not ap- (A)
plied on axle. Failure to follow this rule may
damage the wheel bearings.
4) Remove the stabilizer link. (B)
SEDAN:
(C)
DS-00042
(A) Cotter pin
(B) Castle nut
(C) Tie-rod
8) Using a puller, remove the tie-rod ball joint from
FS-00048
knuckle arm.
WAGON:
DS-00043
FS-00070
5) Remove the disc brake caliper from housing,
and suspend it from strut using a wire.
DS-17
FRONT AXLE
DRIVE SHAFT SYSTEM
9) Remove the ABS wheel speed sensor assembly 12) After scribing an alignment mark on the camber
and harness. adjusting bolt head, remove the bolts which con-
nect the housing and strut, and disconnect the
housing from strut.
DS-00044
10) Remove the transverse link ball joint from DS-00046
housing.
B: INSTALLATION
1) Temporarily tighten the front axle to front strut.
2) Insert the front drive shaft into front axle.
3) Temporarily tighten the axle nut.
4) Install the transverse link ball joint to housing.
Tightening torque:
